Cisco Catalyst 9200L-48T-4X-A 48-Port Switch 4×10G Uplinks/Advantage
Cisco Catalyst 9200L-48T-4X-A 48-Port Gigabit Data Switch with 4×10 Gbps Uplinks, Network Advantage
The Cisco Catalyst 9200L-48T-4X-A is a 1 RU fixed-uplink access switch in the Catalyst 9200L family, engineered for high-density branch and small-campus deployments.
It provides 48 auto-sensing 10/100/1000 Mbps RJ-45 data-only ports and four fixed 10 Gbps SFP+ uplinks, powered by a single PWR-C5-125WAC AC platinum-efficient PSU with fixed redundant fans.
Built on Cisco’s UADP 2.0 Mini ASIC with 2 GB DRAM and 4 GB flash, it runs Cisco IOS XE with the Network Advantage license, supports StackWise-80 stacking up to 80 Gbps of bidirectional backplane bandwidth, and integrates seamlessly with Cisco DNA Center or Meraki Dashboard for unified management and automation.
Overview
Highlights
-
48×1 GbE Downlinks
10/100/1000 RJ-45 data-only autosensing ports, ideal for dense wired access. -
4×10 Gbps Fixed Uplinks
Four SFP+ ports for high-speed aggregation—no optional modules required. -
176 Gbps Switching Capacity & 261.9 Mpps Forwarding
Non-blocking fabric delivers wire-speed performance across all ports. -
StackWise-80 Stacking
Stateful stacking of up to eight switches with 80 Gbps bidirectional backplane bandwidth and sub-50 ms failover. -
Data-Only, Energy-Efficient Design
No PoE overhead; IEEE 802.3az Energy-Efficient Ethernet and fixed redundant fans reduce power consumption. -
Enterprise-Grade Security
Line-rate AES-128 MACsec, Secure Boot with Trust Anchor, 802.1X, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard, and scalable ACLs. -
Flexible Management & Automation
Manage via CLI, embedded Web UI, SNMP v1/v2c/v3, RMON, NETCONF/RESTCONF, Plug and Play; native integration with Cisco DNA Center and Meraki Dashboard. -
Advanced Software Features (Network Advantage)
Enables VRF, VXLAN, LISP, SGT segmentation; advanced routing (EIGRP, OSPF, BGP, IS-IS); model-driven APIs and streaming telemetry; SD-Access assurance.
Recommended Accessories
| Accessory | Category | Description |
|---|---|---|
| C9200L-STACK-KIT= | Stacking Module | StackWise-80 kit (2 adapters + cable) |
| STACK-T4-50CM/1M/3M | Stacking Cable | Type 3 stacking cables (0.5 m, 1 m, 3 m) |
| PWR-C5-125WAC | Power Supply | 125 W AC platinum-efficient PSU (fixed) |
Comparison with Similar Models
| Model | Downlinks | Uplinks | License | Stacking |
|---|---|---|---|---|
| C9200L-48T-4X-A | 48×1 GbE data-only | 4×10 Gbps SFP+ | Advantage | 80 Gbps |
| C9200L-48T-4X-E | 48×1 GbE data-only | 4×10 Gbps SFP+ | Essentials | 80 Gbps |
| C9200L-48P-4X-A | 48×1 GbE PoE+ | 4×10 Gbps SFP+ | Advantage | 80 Gbps |
Specifications
| Parameter | Specification |
|---|---|
| Product Code | C9200L-48T-4X-A |
| Description | Catalyst 9200L 48-port data-only switch with 4×10 Gbps uplinks, Network Advantage license |
| Downlink Ports | 48× 10/100/1000 RJ-45 data-only |
| Uplink Ports | 4× 10 Gbps SFP+ fixed |
| Switching Capacity | 176 Gbps non-blocking |
| Forwarding Rate | 261.9 Mpps (64-byte packets) |
| Stacking Bandwidth | 80 Gbps (StackWise-80) |
| DRAM / Flash | 2 GB DRAM; 4 GB flash |
| Power Supply | PWR-C5-125WAC AC platinum-efficient (fixed redundant) |
| Fans | Fixed, redundant |
| Software | Cisco IOS XE with Network Advantage |
| Chassis Dimensions (H×W×D) | 1.73″×17.5″×11.3″ (4.4×44.5×28.8 cm) |
| Virtual Networks | 1 |
| Mean Time Between Failures (MTBF) | 503,400 hours |
