Cisco Catalyst 9300-48P-E Essentials License 48-Port PoE+ Switch
Cisco C9300-48P-E Access Enterprise Campus Switch
The Cisco Catalyst 9300-48P-E is a 1 RU, fixed-access enterprise campus switch built for mission-critical U.S. networks—from Silicon Valley innovation labs to Wall Street trading floors.
As part of the Catalyst 9300 family, it delivers 48 auto-sensing 10/100/1000 PoE+ ports with a 437 W PoE budget, hot-swappable field-replaceable fans, and support for optional modular uplinks via Cisco network modules.
Running Cisco IOS XE with the Network Essentials license, it offers enterprise-grade security, energy efficiency (ENERGY STAR® certified), and seamless integration with Cisco DNA Center or Meraki cloud monitoring.
Overview
Highlights
-
Ports & Uplink Flexibility
48 × 10/100/1000 RJ-45 PoE+ downlinks; supports optional Cisco network modules (e.g., 4×1 GbE SFP, 8×10 GbE SFP+, 2×40 GbE QSFP+) for uplinks. -
Power over Ethernet
Full 48-port PoE+ (30 W per port) with a 437 W total PoE budget, powering IP phones, cameras, and Wi-Fi 6 access points. -
High Performance
256 Gbps non-blocking switching capacity and 190.47 Mpps forwarding rate keep your east-west campus traffic flowing at wire speed. -
Stacking & Resiliency
StackWise-480 supports up to 8 switches in a single stack at 480 Gbps of stack bandwidth; NSF/SSO, cross-stack EtherChannel, and err-disable recovery for sub-50 ms failover. -
Enterprise-Grade Security
AES-256 MACsec encryption, Secure Boot with Trust Anchor Module, 802.1X, DHCP snooping, Dynamic ARP Inspection, IP Source Guard, and robust ACL scale. -
Energy Efficiency
ENERGY STAR® certified with IEEE 802.3az Energy Efficient Ethernet, deep-sleep port modes, and low-power fan management for U.S. sustainability goals. -
Flexible Management
CLI, embedded Web UI, SNMP v1/v2c/v3, RMON, NETCONF/RESTCONF, Plug and Play, plus full Cisco DNA Center and Meraki Dashboard integration for zero-touch provisioning.
Recommended Accessories
| Accessory | Category | Description |
|---|---|---|
| C9300-NM-4G | Network Module | 4×1 GbE SFP uplink module for compact fiber connectivity |
| C9300-NM-8X | Network Module | 8×10 GbE SFP+ uplink module for high-speed aggregation |
| C9300-NM-2Q | Network Module | 2×40 GbE QSFP+ uplink module for ultra-high-speed uplinks |
| PWR-C1-715WAC | Power Supply | 715 W AC platinum-rated PSU (default) for PoE+ and system power |
| PWR-C1-1100WAC | Power Supply | 1,100 W AC platinum-rated PSU for expanded PoE or dual-PS redundancy |
| FAN-T2= | Fan Module | Field-replaceable fan tray supporting N+1 redundancy |
Comparison with Similar Models
| Feature | C9300-48P-E | C9300-24P-A | C9300-48T-E |
|---|---|---|---|
| Ports & Uplinks | 48×1 GbE PoE+ + modular uplinks | 24×1 GbE PoE+ + modular uplinks | 48×1 GbE data-only + modular uplinks |
| License | Network Essentials | Network Advantage | Network Essentials |
| Available PoE Power | 437 W | 445 W | N/A |
| Switching Capacity | 256 Gbps | 208 Gbps | 256 Gbps |
| Forwarding Rate | 190.47 Mpps | 154.76 Mpps | 190.47 Mpps |
| Ideal Use Case | High-density PoE access layer | Mid-density PoE+ with advanced features | Full-density data-only edge aggregation |
Specifications
| Parameter | Specification |
|---|---|
| Model | Cisco C9300-48P-E |
| Software | Cisco IOS XE 16.x with Network Essentials license |
| Downlink Ports | 48 × 10/100/1000 PoE+ RJ-45 auto-sensing ports |
| Uplink Options | Optional network modules (C9300-NM-4G, -8X, -2Q) |
| Switching Capacity | 256 Gbps full-duplex |
| Forwarding Rate | 190.47 Mpps (64-byte packets) |
| MAC Address Table | 32,000 entries |
| IPv4 Routes | 32,000 (24,000 direct + 8,000 indirect) |
| IPv6 Routes | 16,000 entries |
| Multicast Routes | 8,000 entries |
| QoS Scale Entries | 5,120 entries |
| ACL Scale Entries | 5,120 entries |
| Packet Buffer | 16 MB buffer |
| Flexible NetFlow | 64,000 flows |
| DRAM / Flash | 8 GB DRAM; 16 GB flash |
| Stacking | StackWise-480; 480 Gbps; up to 8 members |
| Energy Efficiency | IEEE 802.3az EEE; ENERGY STAR® certified |
| Power Supplies | Dual slots; default PWR-C1-715WAC; optional PWR-C1-1100WAC |
| Power Consumption | 715 W AC PSU; system draw approx. 50 W (excl. PoE) |
| Operating Temperature | 32 °F to 113 °F (0 °C to 45 °C) |
| Dimensions (HxWxD) | 1.73″ × 17.5″ × 17.5″ (44 × 444 × 444 mm) |
| Weight | 16.33 lb (7.4 kg) |
| Management | CLI, Web UI, SNMP v1/v2c/v3, RMON, NETCONF/RESTCONF, Cisco DNA Center, Meraki Dashboard |
| Security | MACsec, Secure Boot, 802.1X, DHCP Snooping, DAI, IP Source Guard, Trust Anchor Module |
| Certifications | UL, CSA, FCC Class A, CE, RoHS, ENERGY STAR® |
More Details
Quality Certifications
Warranty
100% Low Price Guarantee
Network-switch.com provides high-quality products at low wholesale prices
100% Quality Assurance
All items are ORIGINAL and GENUINE only.
Item conditions are "New Sealed". They are fully tested by CCIE Engineers.
Free Technical Support
Our FREE Expert Consultancy Support is over the phone, by chat, by email or by login remotely.
100% Money Back Guarantee
You can contact our customer service team to exchange or return any product that you bought from us.
Flexible Secure Payment & Shipment
Verified authorization: Mcafee Secure, VeriSign Secured
Return Material Authorization (RMA) Process
Standard Warranty Policy
Original New Sealed Enterprise Hardware: 3 Years
Original New Sealed Consumer Devices: 1 Year
The Support Contacts
If your Cisco products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
