Ruijie RG-S6930-2C 2RU 2-Slot 100GE Data Center Switch(Chassis)
Ruijie RG-S6930-2C Next-Generation Data Center Modular Core Switch
The Ruijie RG-S6930-2C is a high-density modular switch that serves as the core of the next-generation data center and high-performance computing.
The versatile models feature (1 + 1) redundant CPUs and two service slots to host 100GE and 200GE line cards for up to 144 × 100GE or 72 × 200GE ports. It has a switching capacity of 28.8 Tbps and a packet forwarding rate of 5,400 Mpps.
RG-S6930-2C also has MACsec hardware encryption, telemetry and front-to rear airflow. The system's modular architecture and hot-pluggable components, are highly scalable and highly available, making it an ideal platform for data center gateways, metropolitan area networks (MANs), and data center interconnect (DCI) applications.
Overview
Highlights
-
High-Density Port Configuration: Supports up to 144 × 100GE or 72 × 200GE ports, providing flexibility for diverse networking requirements.
-
Advanced Architecture: Clos orthogonal design delivers non-blocking forwarding and high-speed transmission without packet loss.
-
Secure Data Transmission: MACsec hardware-level encryption ensures secure data transmission and protects against unauthorized access.
-
Telemetry-Based Monitoring: Real-time network monitoring with sub-second granularity enables efficient management and rapid fault detection.
-
Robust Redundancy: 2+2 hot-swappable power modules and 7+1 hot-swappable fan modules ensure continuous operation and service reliability.
-
Efficient Cooling: Front-to-rear airflow design enhances cooling efficiency, contributing to system stability and longevity.
Recommended Accessories
Here are some compatible accessories to enhance the functionality of the Ruijie RG-S6930-2C:
| Product Name | Category | Description |
| M6900-36CQ18DC-CES | Line Card Module |
Provides 36 × 100GE QSFP28 ports and 18 × 200GE QSFP56 ports, supporting high-density connectivity. |
| PSA1300CRPS-F-RJ | Power Supply Module |
1300W AC/HVDC power supply module, supporting 2+2 redundancy for uninterrupted power. |
| FAN12K8080-F-RJ | Fan Module |
High-efficiency fan module with intelligent speed adjustment for optimal cooling performance. |
Comparison with Similar Models
| Model | Port Configuration | Switching Capacity | Packet Forwarding Rate |
|---|---|---|---|
| RG-S6930-2C | 144 × 100 GE or 72 × 200 GE (2 slots) | 28.8 Tbps | 5400 Mpps |
| RG-S6980-64QC | 64 × 400 GE QSFP-DD | 51.2 Tbps | 10300 Mpps |
| RG-S6580-24DC8QC | 24 × 200 GE QSFP56 + 8 × 400 GE QSFP-DD | 16.0 Tbps | 5350 Mpps |
| RG-S6510-48VS8CQ | 48 × 25 GE SFP28 + 8 × 100 GE QSFP28 | 4.0 Tbps | 2000 Mpps |
Specifications
| Parameter | Specification |
| Model | RG-S6930-2C |
| Service Slots | 2 |
| Switching Capacity | 28.8 Tbps |
| Packet Forwarding Rate | 5,400 Mpps |
| Port Configurations | Supports up to 144 × 100GE or 72 × 200GE ports |
| Buffer Capacity | 16 GB |
| Power Module Slots | 4 (supporting 2+2 redundancy) |
| Fan Module Slots | 8 (supporting 7+1 redundancy) |
| Management Ports | 1 × Management, 1 × Console, 1 × USB 2.0 |
| Dimensions (W × D × H) | 442 mm × 760 mm × 175 mm (17.40 in. × 29.92 in. × 6.89 in., 4 RU) |
| Weight | Approximately 33.55 kg (including fan and power modules) |
| Power Supply | AC 100–240V or HVDC 240V |
| Maximum Power Consumption | 2,934 W (typical: 1,338 W; static: 600 W) |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | –40°C to +70°C (–40°F to 158°F) |
| Operating Humidity | 10% to 90% RH (non-condensing) |
| Storage Humidity | 5% to 95% RH (non-condensing) |
| Altitude | Operating: up to 5,000 m (16,404 ft.) |
| MTBF | ≥ 200,000 hours |
More Details
Quality Certifications
Warranty
100% Low Price Guarantee
Network-switch.com provides high-quality products at low wholesale prices
100% Quality Assurance
All items are ORIGINAL and GENUINE only.
Item conditions are "New Sealed". They are fully tested by Ruijie RCNP Engineers.
Free Technical Support
Our FREE Expert Consultancy Support is over the phone, by chat, by email or by login remotely.
100% Money Back Guarantee
You can contact our customer service team to exchange or return any product that you bought from us.
Flexible Secure Payment & Shipment
Verified authorization: Mcafee Secure, VeriSign Secured
Return Material Authorization (RMA) Process
Standard Warranty Policy
Original New Sealed Enterprise Hardware: 3 Years
Original New Sealed Consumer Devices: 1 Year
The Support Contacts
If your Ruijie products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
