Ruijie RG-S6980-64QC 4RU 64×400G QSFP-DD Core Switch
Ruijie RG-S6980-64QC Next-Generation Data Center 400GE Core Switch
The Ruijie RG-S6980-64QC is a high-performance, fixed-configuration 4 RU core switch designed for next-generation data centers.
It houses 64 × 400 GE QSFP-DD ports, delivering up to 51.2 Tbps of non-blocking switching capacity and 10 300 Mpps line-rate forwarding—ideal for AI/ML, high-performance computing, big-data, and distributed storage environments.
Leveraging PFC, ECN, and MMU-based buffer enhancements, the RG-S6980-64QC ensures lossless RDMA fabrics, while 2+2 hot-swappable power and 7+1 hot-swappable fan modules guarantee carrier-class reliability without service interruption
Overview
Highlights
-
High-Density Port Configuration: 64 × 400GE QSFP-DD ports in a 4RU chassis, supporting up to 51.2 Tbps switching capacity.
-
Advanced Architecture: Clos orthogonal design delivers non-blocking forwarding and high-speed transmission without packet loss.
-
Lossless Ethernet: Supports RDMA, PFC, and ECN technologies for zero packet loss and low-latency data transmission.
-
Robust Redundancy: 2+2 hot-swappable power modules and 7+1 hot-swappable fan modules ensure continuous operation and service reliability.
-
Telemetry-Based Monitoring: Real-time network monitoring with sub-second granularity for efficient management.
-
Comprehensive Protocol Support: Supports IPv4/IPv6 dual-stack, BGP, OSPF, IS-IS, RIP, and various tunneling technologies.
Recommended Accessories
Here are some compatible accessories to enhance the functionality of the Ruijie RG-S6980-64QC:
| Product Name | Category | Description |
| M2EFAN II-F | Fan Module |
High-efficiency fan module with intelligent speed adjustment for optimal cooling. |
| RG-PA3000I-F | Power Supply Module |
3000W AC/HVDC power supply module, supporting 2+2 redundancy for uninterrupted power. |
| 400GE ZR/ZR+ Optical Modules | Optical Transceivers |
Support long-distance interconnection up to 120 km, ideal for data center interconnect (DCI) scenarios. |
Comparison with Similar Models
| Model | Port Configuration | Switching Capacity | Packet Forwarding Rate |
|---|---|---|---|
| RG-S6980-64QC | 64 × 400 GE QSFP-DD | 51.2 Tbps | 10 300 Mpps |
| RG-S6580-24DC8QC | 24 × 200 GE QSFP56 + 8 × 400 GE QSFP-DD | 16.0 Tbps | 5 350 Mpps |
| RG-S6580-48CQ8QC | 48 × 100 GE DSFP + 8 × 400 GE QSFP-DD | 16.0 Tbps | 5 350 Mpps |
| RG-S6510-48VS8CQ | 48 × 25 GE SFP28 + 8 × 100 GE QSFP28 | 4.0 Tbps | 2 000 Mpps |
| RG-S6250-48XS8CQ | 48 × 10 GE SFP+ + 8 × 100 GE QSFP28 | 4.8 Tbps | 2 000 Mpps |
Specifications
| Parameter | Specification |
| Model | RG-S6980-64QC |
| Ports | 64 × 400GE QSFP-DD |
| Switching Capacity | 51.2 Tbps |
| Packet Forwarding Rate | 10,300 Mpps |
| Buffer Capacity | 113.66 MB |
| VLANs | 4,094 |
| Routing Entries | IPv4: 1,000K; IPv6: 640K |
| Management Ports | 1 × Management, 1 × Console, 1 × USB 2.0 |
| Power Module Slots | 4 |
| Fan Module Slots | 8 |
| Dimensions (W × D × H) | 442 mm × 735 mm × 173.6 mm (17.40 in. × 28.94 in. × 6.83 in., 4 RU) |
| Weight | Approximately 48 kg (including fan and power modules) |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Storage Temperature | –40°C to +70°C (–40°F to 158°F) |
| Operating Humidity | 10% to 90% RH (non-condensing) |
| Storage Humidity | 5% to 95% RH (non-condensing) |
| Altitude | Operating: up to 5,000 m (16,404 ft.) |
| MTBF | ≥ 200,000 hours |
More Details
Quality Certifications
Warranty
100% Low Price Guarantee
Network-switch.com provides high-quality products at low wholesale prices
100% Quality Assurance
All items are ORIGINAL and GENUINE only.
Item conditions are "New Sealed". They are fully tested by Ruijie RCNP Engineers.
Free Technical Support
Our FREE Expert Consultancy Support is over the phone, by chat, by email or by login remotely.
100% Money Back Guarantee
You can contact our customer service team to exchange or return any product that you bought from us.
Flexible Secure Payment & Shipment
Verified authorization: Mcafee Secure, VeriSign Secured
Return Material Authorization (RMA) Process
Standard Warranty Policy
Original New Sealed Enterprise Hardware: 3 Years
Original New Sealed Consumer Devices: 1 Year
The Support Contacts
If your Ruijie products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
Original: $193,967.00
-70%$193,967.00
$58,190.10More Images
