Huawei AirEngine 6760-X1 Indoor Wi-Fi 6 AP, 10.75 Gbps, 10-Stream SDR
Huawei AirEngine 6760-X1: Indoor Wi-Fi 6 AP with up to 10.75 Gbps & Smart Antennas
The Huawei AirEngine 6760-X1 is an indoor Wi-Fi 6 (802.11ax) access point that delivers simultaneous dual-band service—4×4 MIMO on 2.4 GHz and 6×6 MIMO on 5 GHz—for up to 8.35 Gbps out of the box and 10.75 Gbps with an RTU license.
Built-in co-planar Smart Antennas follow users to suppress interference and extend coverage by 20%, while dual 10 GE uplink ports (optical and electrical) and integrated IoT/Bluetooth support enable flexible, high-density deployments in offices, campuses, and large venues.
Overview
Highlights
-
Dual-Radio 4x4 MIMO: Simultaneously operates on 2.4 GHz and 5 GHz bands with 4x4 MIMO, providing robust and reliable wireless coverage.
-
Smart Antenna Technology: Incorporates built-in smart antennas that dynamically adjust signal direction, enhancing coverage and reducing interference.
-
High-Speed Connectivity: Achieves a combined peak data rate of up to 8.35 Gbps under default configuration, with potential to reach 10.75 Gbps through RTU license upgrades.
-
Flexible Radio Modes: Supports software-defined radio (SDR) technology, allowing flexible switching between dual-radio, triple-radio, and dual-radio plus scanning radio modes to adapt to various deployment scenarios.
-
Versatile Uplink Options: Equipped with multiple uplink ports, including 1 × 10 GE electrical, 1 × GE electrical, and 1 × 10 GE SFP+, facilitating flexible network deployment.
-
High User Capacity: Supports up to 1024 concurrent users in dual-radio mode and up to 1152 users in triple-radio mode, making it ideal for high-density environments.
-
Advanced Security: Offers robust security features including WPA3 encryption, 802.1X authentication, and rogue device monitoring, ensuring network integrity.
-
Intelligent Management: Compatible with Huawei’s CloudCampus platform and supports multiple management modes (Cloud / Fit / Fat) for simplified operations and maintenance .
Recommended Accessories
| Product Model | Category | Description |
|---|---|---|
| L-AP6760-X1-1AP | 1-AP License | License to manage one AP |
| L-AP6760-X1-10AP | 10-AP License | License to manage up to ten APs |
| AP-Mount-Kit | Ceiling/Pole-Mount Kit | Mounting hardware for indoor installations |
| SFP-GE-LX10-SM1310 | Optical Transceiver | 1000Base-LX SFP, LC-connector, 10 km over SMF |
Comparison with Similar Models
| Model | Peak Rate | Antennas | Uplink Ports |
|---|---|---|---|
| AirEngine 6760-X1 | 8.35 Gbps (10.75 Gbps RTU) | Built-in Smart | 1×10 GE SFP+; 1×10 GE RJ45 |
| AirEngine 6760R-51E | 5.95 Gbps | External ports | 1×10 GE SFP+; 1×5 GE; 1×GE |
| AirEngine 6760R-51 | 5.95 Gbps | Built-in Smart | 1×10 GE SFP+; 1×5 GE; 1×GE |
| AirEngine 6761-21 | 5.375 Gbps | Built-in Smart | 2×GE RJ45 |
| AirEngine 6761-21T | 6.575 Gbps | Built-in Smart | 1×2.5 GE; 1×10 GE SFP+ |
Specification
| Parameter | Specification |
|---|---|
| Model | AirEngine 6760-X1 |
| Wi-Fi Standards | IEEE 802.11a/b/g/n/ac/ac Wave 2/ax |
| Radio Configuration | Dual-radio: 2.4 GHz (4x4 MIMO), 5 GHz (4x4 MIMO); Upgradable to 5 GHz (8x8 MIMO) with RTU license |
| Peak Data Rate | Up to 8.35 Gbps (default), up to 10.75 Gbps (with RTU license) |
| Ethernet Ports | 1 × 10 GE electrical, 1 × GE electrical, 1 × 10 GE SFP+ |
| Antenna Type | Built-in smart antennas |
| Power Supply | PoE: IEEE 802.3bt compliant; DC: 48 V ±10% |
| Maximum Power Consumption | 35.3 W |
| Security | WPA3, WPA2, WPA, 802.1X, rogue device monitoring |
| Management | Cloud, Fit, and Fat modes; compatible with CloudCampus |
| Operating Temperature | –10°C to +50°C |
| Storage Temperature | –40°C to +70°C |
| Operating Humidity | 5% to 95% RH (non-condensing) |
| Storage Humidity | 5% to 95% RH (non-condensing) |
| Dimensions (H × W × D) | 61 mm × 220 mm × 220 mm |
| Weight | 3 kg |
| Warranty | Limited lifetime warranty |
More Details
Quality Certifications
Warranty
100% Low Price Guarantee
Network-switch.com provides high-quality products at low wholesale prices
100% Quality Assurance
All items are ORIGINAL and GENUINE only.
Item conditions are "New Sealed". They are fully tested by Huawei HCIE Engineers.
Free Technical Support
Our FREE Expert Consultancy Support is over the phone, by chat, by email or by login remotely.
100% Money Back Guarantee
You can contact our customer service team to exchange or return any product that you bought from us.
Flexible Secure Payment & Shipment
Verified authorization: Mcafee Secure, VeriSign Secured
Return Material Authorization (RMA) Process
Standard Warranty Policy
Original New Sealed Enterprise Hardware: 3 Years
Original New Sealed Consumer Devices: 1 Year
The Support Contacts
If your Huawei products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
