Huawei AirEngine 8760-X1-PRO Wi-Fi 6 AP, 10.75 Gbps, 16T16R Smart Antennas
Huawei AirEngine 8760-X1-PRO Indoor Wi-Fi 6 AP — 16T16R Smart Antennas & 10.75 Gbps Device Rate
The AirEngine 8760-X1-PRO is Huawei’s flagship indoor Wi-Fi 6 (802.11ax) access point, featuring 16T16R built-in co-planar Smart Antennas that “follow” users to suppress interference, double signal strength, and extend coverage by ~20 percent.
It flexibly switches among dual-radio, triple-radio, and dual-radio + independent scanning modes, achieving up to 10.75 Gbps aggregate device throughput. Uplink connectivity includes 2×10 GE electrical and 1×10 GE SFP+ ports (all PoE-powered per IEEE 802.3bt), plus built-in BLE 5.2 and IoT card slots for seamless O&M and IoT expansion.
Ideal for high-density scenarios—enterprise offices, campuses, and education—with support for up to 1 152 users in triple-radio mode.
Overview
Highlights
-
Tri-Radio 4x4/8x8 MIMO: Supports flexible switching among three modes: dual-radio (2.4 GHz 4x4 + 5 GHz 12x12), triple-radio (2.4 GHz 4x4 + 5 GHz 8x8 + 5 GHz 4x4), and dual-radio with independent scanning radio, achieving a combined peak data rate of up to 10.75 Gbps.
-
Smart Antenna Technology: Features 16 built-in dual-band smart antennas that dynamically adjust signal coverage, enhancing signal quality and reducing interference.
-
High-Speed Connectivity: Equipped with 2 × 10 GE electrical ports and 1 × 10 GE SFP+ port, facilitating flexible network deployment.
-
IoT Expansion: Provides built-in IoT slots supporting application expansion for BLE 5.2, ZigBee, RFID, and Thread, enabling flexible IoT application extensions.
-
Independent Radio Scanning: Includes a dedicated scanning radio for real-time detection of interference and rogue devices, ensuring optimal network performance.
-
Built-in Bluetooth 5.2: Supports Bluetooth serial interface-based O&M through the CloudCampus APP and precise locating of Bluetooth terminals by collaborating with eSight.
-
High User Capacity: Supports up to 1024 concurrent users in dual-radio mode and up to 1152 users in triple-radio mode, making it ideal for high-density environments.
-
Advanced Security: Offers robust security features including WPA3 encryption, 802.1X authentication, and rogue device monitoring, ensuring network integrity.
-
Intelligent Management: Compatible with Huawei’s CloudCampus platform and supports multiple management modes (Cloud / Fit / Fat) for simplified operations and maintenance.
Recommended Accessories
| Accessory | Category | Description |
|---|---|---|
| IEEE 802.3bt PoE++ Injector | Power | Supplies up to 90 W per port for long-reach PoE++ deployments |
| 10 GE SFP+ Transceiver (SR) | Uplink Module | 10GBASE-SR, 850 nm, LC duplex, up to 300 m (OM3) |
| ZigBee/RFID USB Module | IoT Expansion | USB 2.0 adapter for external IoT protocols (ZigBee, RFID) |
| Ceiling/Wall Mount Kit | Installation | Corrosion-resistant brackets for versatile indoor mounting |
Comparison with Similar Models
| Model | Spatial Streams & Bands | Peak Rate | Uplinks |
|---|---|---|---|
| AirEngine 8760-X1-PRO | 4×[email protected] GHz + 12×12@5 GHz (16T16R) | 10.75 Gbps | 2×10 GE electrical; 1×10 GE SFP+ |
| AirEngine 8761-X1 | 4×[email protected] GHz + 8×8@5 GHz (12T12R) | 5.95 Gbps | 1×10 GE RJ45; 1×GE RJ45 |
| AirEngine 8760R-X1 | 4×[email protected] GHz + 12×12@5 GHz (16T16R) | 10.75 Gbps | 1×10 GE SFP+; 1×10 GE electrical; 1×1 GE RJ45 |
Specification
| Parameter | Specification |
|---|---|
| Model | AirEngine 8760-X1-PRO |
| Wi-Fi Standards | IEEE 802.11a/b/g/n/ac/ac Wave 2/ax |
| Radio Configuration | Tri-radio: 2.4 GHz (4x4 MIMO), 5 GHz (8x8 MIMO), 5 GHz (4x4 MIMO) |
| Peak Data Rate | Up to 10.75 Gbps |
| Ethernet Ports | 2 × 10 GE electrical, 1 × 10 GE SFP+ |
| Antenna Type | Built-in dual-band smart antennas |
| Power Supply | PoE: IEEE 802.3bt compliant; DC: 48 V ±10% |
| Maximum Power Consumption | 35.3 W |
| Security | WPA3, WPA2, WPA, 802.1X, rogue device monitoring |
| Management | Cloud, Fit, and Fat modes; compatible with CloudCampus |
| Operating Temperature | –10°C to +50°C |
| Storage Temperature | –40°C to +70°C |
| Operating Humidity | 5% to 95% RH (non-condensing) |
| Storage Humidity | 5% to 95% RH (non-condensing) |
| Dimensions (H × W × D) | 61 mm × 220 mm × 220 mm |
| Weight | 3 kg |
| Warranty | Limited lifetime warranty |
More Details
Quality Certifications
Warranty
100% Low Price Guarantee
Network-switch.com provides high-quality products at low wholesale prices
100% Quality Assurance
All items are ORIGINAL and GENUINE only.
Item conditions are "New Sealed". They are fully tested by Huawei HCIE Engineers.
Free Technical Support
Our FREE Expert Consultancy Support is over the phone, by chat, by email or by login remotely.
100% Money Back Guarantee
You can contact our customer service team to exchange or return any product that you bought from us.
Flexible Secure Payment & Shipment
Verified authorization: Mcafee Secure, VeriSign Secured
Return Material Authorization (RMA) Process
Standard Warranty Policy
Original New Sealed Enterprise Hardware: 3 Years
Original New Sealed Consumer Devices: 1 Year
The Support Contacts
If your Huawei products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
Original: $1,457.00
-70%$1,457.00
$437.10More Images
