Ruijie RG-S5760C-48GT4XS-HP-X 48×GE PoE+ & 4×10G SFP+ Core Switch
Ruijie RG-S5760C-48GT4XS-HP-X 48-Port Layer 3 PoE Core/Aggregation Switch, 4-Port 10 G Uplink
Ruijie RG-S5760C-48GT4XS-HP-X Enterprise Layer 3 Managed Switch It has 48 × 10/100/1000BASE-T PoE/PoE+ ports and 4 × 1GE/10GE SFP+ uplink ports.
The switch is equipped with advanced capabilities, including Virtual Switch Unit (VSU) virtualization, field-proven Layer 3 routing protocols, and in-depth security policies, which makes it an ideal solution for aggregation layers in medium to large networks.
Overview
Highlights
-
High-Density PoE Port Configuration: Provides 48 × 10/100/1000BASE-T PoE/PoE+ ports and 4 × 1GE/10GE SFP+ uplink ports, supporting flexible deployment options.
-
VSU Virtualization: Supports Virtual Switch Unit (VSU) technology, allowing multiple physical switches to operate as a single logical unit, simplifying network management and enhancing reliability.
-
Advanced Layer 3 Routing: Offers comprehensive Layer 3 routing protocols, including static routing, RIP, OSPF, IS-IS, and BGP, supporting both IPv4 and IPv6 networks.
-
Robust Security Features: Incorporates multiple security mechanisms such as ACLs, DHCP Snooping, ARP inspection, and support for SSH and SNMPv3 for secure management.
-
High Reliability: Features hot-swappable power modules with redundancy, ensuring continuous operation and service reliability.
-
Efficient Management: Supports various management methods, including CLI, web-based management, Telnet, and integration with Ruijie’s INC for simplified operations and maintenance.
Recommended Accessories
Here are some compatible accessories to enhance the functionality of the Ruijie RG-S5760C-48GT4XS-HP-X:
| Product Model | Category | Description |
| RG-PA600I-P-F | Power Supply Module | 600W AC power supply module, supporting hot-swapping and redundancy. |
| RG-PA1000I-P-F | Power Supply Module | 1000W AC power supply module, supporting hot-swapping and redundancy. |
| M5000X-4XS2CQ | Expansion Module | 4 × 10GE SFP+ ports and 2 × 100GE QSFP28 ports, enhancing uplink capacity. |
| XG-SFP-SR-MM850 | Optical Transceiver | 10GE SR module, SFP+ form factor, LC connector, 850 nm, up to 300 m over OM3 MMF. |
| XG-SFP-LR-SM1310 | Optical Transceiver | 10GE LR module, SFP+ form factor, LC connector, 1310 nm, up to 10 km over SMF. |
Comparison with Similar Models
| Model | Fixed + Uplink Ports | PoE Support | Capacity | Forwarding |
|---|---|---|---|---|
| RG-S5760C-48GT4XS-HP-X | 48×10/100/1000 BASE-T PoE/PoE+ + 4×1 GE/10 GE SFP+ | Yes | 787 Gbps | 586 Mpps |
| RG-S5760C-48GT4XS-X | 48×10/100/1000 BASE-T + 4×1 GE/10 GE SFP+ | No | 787 Gbps | 586 Mpps |
| RG-S5760C-24GT8XS-X | 24×10/100/1000 BASE-T + 8×1 GE/10 GE SFP+ | No | 826 Gbps | 614 Mpps |
| RG-S5760C-48SFP4XS-X | 48×1 GE SFP + 4×1 GE/10 GE SFP+ | No | 787 Gbps | 586 Mpps |
Specifications
| Parameter | Specification |
| Model | RG-S5760C-48GT4XS-HP-X |
| Service Ports | 48 × 10/100/1000BASE-T PoE/PoE+ |
| Uplink Ports | 4 × 1GE/10GE SFP+ |
| Switching Capacity | 880 Gbps |
| Packet Forwarding Rate | 402 Mpps |
| MAC Address Table | 64,000 entries |
| ARP Table Size | 24,000 entries |
| IPv4 Unicast Routes | 24,000 entries |
| IPv6 Unicast Routes | 14,000 entries |
| IPv4 Multicast Routes | 4,000 entries |
| IPv6 Multicast Routes | 2,000 entries |
| Power Module Slots | 2 (supporting 1+1 redundancy) |
| Fan Module Slots | 2 pluggable modular fans |
| Management Ports | 1 × Management, 1 × Console, 1 × USB 2.0 |
| Expansion Slots | 1 × expansion module slot |
| Dimensions (W × D × H) | 442 mm × 420 mm × 43.6 mm (17.40 in. × 16.54 in. × 1.72 in., 1 RU) |
| Weight | Approximately 5.7 kg (including all modules) |
| Power Supply | AC 100–240V, HVDC 192–288V |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Operating Humidity | 10% to 90% RH (non-condensing) |
| MTBF | ≥ 200,000 hours |
More Details
Quality Certifications
Warranty
100% Low Price Guarantee
Network-switch.com provides high-quality products at low wholesale prices
100% Quality Assurance
All items are ORIGINAL and GENUINE only.
Item conditions are "New Sealed". They are fully tested by Ruijie RCNP Engineers.
Free Technical Support
Our FREE Expert Consultancy Support is over the phone, by chat, by email or by login remotely.
100% Money Back Guarantee
You can contact our customer service team to exchange or return any product that you bought from us.
Flexible Secure Payment & Shipment
Verified authorization: Mcafee Secure, VeriSign Secured
Return Material Authorization (RMA) Process
Standard Warranty Policy
Original New Sealed Enterprise Hardware: 3 Years
Original New Sealed Consumer Devices: 1 Year
The Support Contacts
If your Ruijie products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
