Ruijie RG-S5350-24GT4XS-E 24×Gigabit & 4×10G SFP+ L2+ Switch
Ruijie RG-S5350-24GT4XS-E 24-Port GE Layer 3 Access Switch, 4×1 GE/10 GE SFP+ Uplinks, Essentials
The RG-S5350-24GT4XS-E is part of Ruijie’s Simplified Gigabit Switch RG-S5350 series, designed for large-sized enterprise and campus networks.
It provides 24 auto-negotiating 10/100/1000 BASE-T downlink ports and four fixed SFP+ slots compatible with both 1 GE and 10 GE optics. Powered by a dual-core 1.0 GHz CPU with 1 GB DDR4 and 4 MB packet buffer, it delivers 154 Gbps of non-blocking switching capacity and a forwarding rate of 115 Mpps.
Housed in a compact 1 RU chassis (442 × 220 × 43.6 mm) with a fixed AC power supply, it supports VSU virtualization for up to four members and integrates hardware CPU Protection Policy (CPP) and Network Foundation Protection Policy (NFPP) for robust control-plane stability.
Overview
Highlights
- Support 128 Gbps switching capacity, 96 Mpps forwarding rate.
- RG-S5350-24GT4XS-E provides advanced security functions such as IEEE 802.1X authentication, IP Source Guard and Dynamic ARP Inspection, which can help prevent unauthorized access and security threats from on the network.
- Management: This switch supports SNMP, Web and CLI for easy configuration, monitoring, and maintenance by network administrators.
Recommended Accessories
Here are some compatible accessories to enhance the functionality of the Ruijie RG-S5350-24GT4XS-E:
| Product Name | Category | Description |
| Ruijie RG-PA150IB-F | Power Supply Units |
150W AC power supply module, suitable for industrial switches like the RG-S5350-24GT4XS-E. |
| Ruijie RG-PD150IB-F | Power Supply Units |
150W DC power supply module, offering a compact solution for smaller setups. |
| Ruijie RG-PA600I-P-F | Power Supply Units |
600W AC power supply module, providing higher power output for demanding applications. |
|
MokerLink 1U Rack Mount Kit |
Rack Mount Kits |
Compatible with 19-inch switches, including the RG-S5350-24GT4XS-E, facilitating secure rack installation. |
| Ruijie XG-SFP-SR-MM850 | SFP Transceivers |
10G SFP+ transceiver with 850nm wavelength, suitable for short-range fiber connections. |
Comparison with Similar Models
| Model | Downlinks & Uplinks | PoE Support | Capacity / Forwarding |
|---|---|---|---|
| RG-S5350-24GT4XS-E | 24×GE data-only + 4×10 GE | None | 154 Gbps / 115 Mpps |
| RG-S5350-24GT4XS-P-E | 24×GE PoE+ + 4×10 GE | IEEE 802.3at | 154 Gbps / 115 Mpps |
| RG-S5350-12GT4XS-P-E | 12×GE PoE+ + 4×10 GE | IEEE 802.3at | 125 Gbps / 94 Mpps |
| RG-S5350-48GT4XS-E | 48×GE data-only + 4×10 GE | None | 211 Gbps / 158 Mpps |
Specifications
| Parameter | Specification |
| Model | RG-S5350-24GT4XS-E |
| Port Configuration | 24 x 10/100/1000BASE-T, 4 x 1G/10G SFP+ |
| Switching Capacity | 128 Gbps |
| Forwarding Rate | 96 Mpps |
| MAC Address Table | 32,000 entries |
| ARP Table Size | 4,000/16,000 (authorized) |
| ND Table Size | 2,000/8,000 (authorized) |
| IPv4 Unicast Routes | 8,000/12,000 (authorized) |
| IPv6 Unicast Routes | 4,000 |
| Access Control Entries | Ingress: 3,500; Egress: 1,500 |
| Operating Temperature | 0°C to 45°C |
| Storage Temperature | -40°C to +70°C |
| Power Input | AC: 100V to 240V, 50/60Hz |
| Maximum Power Consumption | 25 W (without PoE load); 40 W (full PoE load) |
| Dimensions (W x D x H) | 442 mm x 220 mm x 43.6 mm |
| Weight | 3.1 kg |
| Mounting | 19-inch rack mount |
| Ingress Protection | IP40 (Protection from solid objects larger than 1mm) |
| ESD Protection | Air discharge: 8 kV / Contact discharge: 6 kV |
