Ruijie RG-S5350-24GT4SFP-E 24×Gigabit & 4×1G SFP L3 Switch
Ruijie RG-S5350-24GT4SFP-E 24-Port GE Layer 3 Managed Access Switch, 4×1 GE SFP Uplinks
The RG-S5350-24GT4SFP-E is part of Ruijie’s S5350-E series of Layer 3 switches, engineered for large-sized enterprise and campus networks.
It provides 24 auto-negotiating 10/100/1000 BASE-T downlink ports and four fixed 1 GE SFP uplinks for high-speed data transmission.
Housed in a fanless, IP 40-rated 1 RU chassis, it delivers 67 Gbps of non-blocking switching capacity and forwards up to 50 Mpps - while features like hardware-level surge protection, CPP/NFPP security policies, VSU virtualization, IEEE 802.3az EEE, and Ruijie INC plug-and-play O&M ensure reliability, robustness, and ease of management.
Overview
Highlights
- 67 Gbps Switching Capacity and 50 Mpps Forwarding Rate: The RG-S5350-24GT4SFP-E boasts a 67 Gbps switching capacity and 50 Mpps forwarding rate, allowing it to efficiently handle high traffic loads and ensuring smooth and uninterrupted network performance.
- Versatile Network Connectivity: This switch features 24 Gigabit Ethernet ports and 4 SFP uplink ports to support various forms of hardware and network topologies.
- The RG-S5350-24GT4SFP-E comes with advanced security features like IEEE 802.1X authentication, IP Source Guard and Dynamic ARP Inspection to protect your network from unauthorized access and security threats.
- This management switch provides SNMP, Web and CLI multiple management interfaces for easy configuration, monitoring, and maintenance.
Recommended Accessories
Here are some compatible accessories to enhance the functionality of the Ruijie RG-S5350-24GT4SFP-E:
| Product Name | Category | Description |
| Ruijie RG-PA150IB-F | Power Supply Units |
150W AC power supply module, suitable for industrial switches like the RG-S5350-24GT4SFP-E. |
| Ruijie RG-PD150IB-F | Power Supply Units |
150W DC power supply module, offering a compact solution for smaller setups. |
| Ruijie RG-PA600I-P-F | Power Supply Units |
600W AC power supply module, providing higher power output for demanding applications. |
| MokerLink 1U Rack Mount Kit | Rack Mount Kits |
Compatible with 19-inch switches, including the RG-S5350-24GT4SFP-E, facilitating secure rack installation. |
| Ruijie XG-SFP-SR-MM850 | SFP Transceivers |
10G SFP+ transceiver with 850nm wavelength, suitable for short-range fiber connections. |
Comparison with Similar Models
| Model | Downlinks & Uplinks | Capacity / Forwarding | PoE Support |
|---|---|---|---|
| RG-S5350-24GT4SFP-E | 24× GE + 4× 1 GE SFP | 67 Gbps / 50 Mpps | None |
| RG-S5350-24GT4SFP-P-E | 24× GE PoE+ + 4× 1 GE SFP | 67 Gbps / 50 Mpps | IEEE 802.3af/at |
| RG-S5350-48GT4SFP-E | 48× GE + 4× 1 GE SFP | 125 Gbps / 94 Mpps | None |
| RG-S5350-24GT4XS-E | 24× GE + 4× 10 GE SFP+ | 154 Gbps / 115 Mpps | None |
Specifications
| Parameter | Specification |
| Model | RG-S5350-24GT4SFP-E |
| Port Configuration | 24 x 10/100/1000BASE-T, 4 x 1GE SFP |
| Switching Capacity | 67 Gbps |
| Forwarding Rate | 50 Mpps |
| MAC Address Table | 16,000 entries |
| ARP Table Size | 4,000 |
| IPv4 Unicast Routes | 6,000 |
| IPv6 Unicast Routes | 2,000 |
| Access Control Entries | Ingress: 1,750; Egress: 800 |
| Operating Temperature | 0°C to 45°C |
| Storage Temperature | -40°C to +70°C |
| Power Input | AC: 100V to 240V, 50/60Hz |
| Maximum Power Consumption | 40 W (without PoE load); 600 W (full PoE load) |
| Dimensions (W x D x H) | 442 mm x 220 mm x 43.6 mm |
| Weight | 3.3 kg |
| Mounting | 19-inch rack mount |
| Ingress Protection | IP40 (Protection from solid objects larger than 1mm) |
| ESD Protection | Air discharge: 8 kV / Contact discharge: 6 kV |
