Ruijie RG-S5350-24GT4XS-P-E 24×Gigabit PoE+ & 4×10G SFP+ L2+ Switch
Ruijie RG-S5350-24GT4XS-P-E 24-Port GE Layer 3 Managed PoE+ Switch, 4×10 GE SFP+ Uplinks
The RG-S5350-24GT4XS-P-E from Ruijie’s RG-S5350-E Essentials series is engineered for high-performance enterprise and campus LANs. It features 24 auto-sensing 10/100/1000 BASE-T PoE/PoE+ downlinks (up to 30 W per port) and four fixed SFP+ slots supporting 1 GE, 2.5 GE, or 10 GE optics.
Powered by a dual-core 1.0 GHz CPU, 1 GB DDR4 memory, 16 MB BootROM and 512 MB flash, and a 4 MB packet buffer, it delivers 154 Gbps of non-blocking switching capacity and a wire-speed forwarding rate of 115 Mpps.
Housed in a 1 RU, IP 40, fanless chassis with a built-in 460 W AC power supply (100–240 VAC, 6 A), it supports VSU virtualization for up to four switches, IEEE 802.3az Energy-Efficient Ethernet (EEE), hardware CPU Protection Policy (CPP), Network Foundation Protection Policy (NFPP), and plug-and-play O&M via Ruijie INC or Cloud.
Overview
Highlights
- Higher Switching Capacity: The RG-S5350-24GT4XS-P-E features a switching capacity of 128 Gbps and a forwarding processor for 96 Mpps, providing efficient processing of heavy loads without causing network congestion or delay.
- PoE Plug: Ports 1 to 24 support IEEE 802.3af/at PoE/PoE+ power supply, providing 30 W of power supply to meet the power supply needs of terminals such as VoIP phones, wireless access points and IP cameras.
- Features of the RG-S5350-24GT4XS-P-E:Flexible Connectivity: 24 Gigabit Ethernet ports, 4 SFP+ Uplink Ports.
- SSH Management: The RG-S5350-24GT4XS-P-E offers Management Layer 2+ Access via SSH for added security and reliability.
- 1676350950 The comprehensive management support this switch provides (SNMP, Web, CLI, etc.) and enables easy configuration, monitoring, and proper maintenance of the switch.
Recommended Accessories
Here are some compatible accessories to enhance the functionality of the Ruijie RG-S5350-24GT4XS-P-E:
| Product Name | Category | Description |
| Ruijie RG-PA150IB-F | Power Supply Units |
150W AC power supply module, suitable for industrial switches like the RG-S5350-24GT4XS-P-E. |
| Ruijie RG-PD150IB-F | Power Supply Units |
150W DC power supply module, offering a compact solution for smaller setups. |
| Ruijie RG-PA600I-P-F | Power Supply Units |
600W AC power supply module, providing higher power output for demanding applications. |
| MokerLink 1U Rack Mount Kit | Rack Mount Kits |
Compatible with 19-inch switches, including the RG-S5350-24GT4XS-P-E, facilitating secure rack installation. |
| Ruijie XG-SFP-SR-MM850 | SFP Transceivers |
10G SFP+ transceiver with 850nm wavelength, suitable for short-range fiber connections. |
Comparison with Similar Models
| Model | Downlinks & Uplinks | Capacity / Forwarding | PoE Budget |
|---|---|---|---|
| RG-S5350-24GT4XS-P-E | 24×GE PoE+/PoE + 4×10 GE SFP+ | 154 Gbps / 115 Mpps | 405 W total |
| RG-S5350-12GT4XS-P-E | 12×GE PoE+/PoE + 4×10 GE SFP+ | 125 Gbps / 94 Mpps | 360 W total |
| RG-S5350-24GT4XS-E | 24×GE + 4×10 GE SFP+ | 154 Gbps / 115 Mpps | None |
| RG-S5350-48GT4XS-P-E | 48×GE PoE+/PoE + 4×10 GE SFP+ | 211 Gbps / 158 Mpps | 1440 W total |
Specifications
| Parameter | Specification |
| Model | RG-S5350-24GT4XS-P-E |
| Port Configuration | 24 x 10/100/1000BASE-T, 4 x 1G/10G SFP+ |
| PoE Support | Ports 1 to 24 support PoE/PoE+ (IEEE802.3af/at) power supply |
| Switching Capacity | 128 Gbps |
| Forwarding Rate | 96 Mpps |
| MAC Address Table | 32,000 entries |
| ARP Table Size | 4,000/16,000 (authorized) |
| ND Table Size | 2,000/8,000 (authorized) |
| IPv4 Unicast Routes | 8,000/12,000 (authorized) |
| IPv6 Unicast Routes | 4,000 |
| Access Control Entries | Ingress: 3,500; Egress: 1,500 |
| Operating Temperature | 0°C to 45°C |
| Storage Temperature | -40°C to +70°C |
| Power Input | AC: 100V to 240V, 50/60Hz |
| Maximum Power Consumption | 25 W (without PoE load); 40 W (full PoE load) |
| Dimensions (W x D x H) | 442 mm x 220 mm x 43.6 mm |
| Weight | 3.1 kg |
| Mounting | 19-inch rack mount |
| Ingress Protection | IP40 (Protection from solid objects larger than 1mm) |
| ESD Protection | Air discharge: 8 kV / Contact discharge: 6 kV |
