Ruijie RG-AP1920 Wall-Plate Wi-Fi 7 AP, 3.570 Gbps, 1×2.5 G & 4×1 G Ports
Ruijie RG-AP1920 Wall-Plate Wi-Fi 7 AP — Dual-Radio 2×2:2 & 4-Stream 3.570 Gbps with 2.5 GbE Uplink
The Ruijie RG-AP1920 is a next-generation Wi-Fi 7 (802.11be) dual-radio wall-plate access point designed to deliver high-speed, reliable wireless connectivity in indoor environments.
With a sleek design compatible with standard 86 mm junction boxes, it seamlessly integrates into various settings such as VIP offices, meeting rooms, hotel suites, and educational institutions.
The RG-AP1920 offers a combined peak data rate of up to 3.570 Gbps, ensuring exceptional performance for bandwidth-intensive applications.
Overview
Highlight
- Wi-Fi 7 Compliance: Supports the latest IEEE 802.11be standard, offering enhanced throughput and reduced latency.
- Dual-Radio Design: Equipped with 2x2 MIMO on both 2.4 GHz and 5 GHz bands, providing a combined peak data rate of up to 3.570 Gbps.
- Flexible Networking: Features a 2.5GBASE-T uplink port, four 1GBASE-T downlink ports, and two pass-through ports, allowing for versatile deployment options and future-proof scalability.
- Smart Antennas: Built-in intelligent antennas dynamically adjust signal strength and coverage to optimize device performance.
- Digital Twin Network: Supports intelligent operations and maintenance functions, improving network efficiency by up to 30%.
- Enhanced Security: Incorporates advanced security features, including WPA3 encryption, to safeguard network integrity.
- Energy-Efficient Design: Supports Energy Efficient Ethernet (EEE) and auto power-down modes to reduce power consumption.
- Efficient Management: Compatible with Ruijie’s Smart Network Commander (SNC) for simplified operations and maintenance.
Recommended Accessories
| Accessory | Category | Description |
|---|---|---|
| 2.5GBASE-SR SFP Module | Uplink Optics | 2.5 GbE SFP multimode, 850 nm, LC duplex, up to 300 m on OM3/OM4 |
| 2.5GBASE-LR SFP Module | Uplink Optics | 2.5 GbE SFP single-mode, 1310 nm, LC duplex, up to 10 km |
| IEEE 802.3at PoE+ Injector | Power | Supplies up to 30 W for RJ45 PoE-powered downlinks |
| 86 mm Junction Box Adapter | Mounting Hardware | Ensures proper fit in American-standard boxes and back-box installations |
Comparison with Similar Models
| Model | Wireless & Rate | Ports |
|---|---|---|
| RG-AP1920 | Wi-Fi 7 dual-radio, 4 streams, 3.570 Gbps | 1×2.5 GbE uplink; 4×1 GbE downlink; 2×100 MbE passthrough |
| RG-AP9220 | Wi-Fi 7 dual-radio, 4 streams, 3.570 Gbps | 1×2.5 GbE uplink; 4×1 GbE downlink (no passthrough) |
| RG-AP810-I | Wi-Fi 6 dual-radio, 4 streams, 2.976 Gbps | 1×2.5 GbE uplink; 4×1 GbE downlink |
Specification
| Parameter | Specification |
| Model | RG-AP1920 |
| Wi-Fi Standards | IEEE 802.11be/ax/ac/n |
| Radio Configuration | Dual-radio, 2x2 MIMO on both 2.4 GHz and 5 GHz bands |
| Peak Data Rate | Up to 3.570 Gbps |
| Ethernet Ports | 1 × 100/1000/2.5GBASE-T uplink port, 4 × 10/100/1000BASE-T downlink ports, 2 × pass-through ports |
| Antenna Type | Built-in smart antennas |
| Power Supply | Supports DC and PoE power supply |
| Security | WPA3, WPA2, WPA, 802.1X, PPSK, etc. |
| Management | Supports Fat, Fit, and Cloud modes; compatible with Ruijie SNC |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Operating Humidity | 10% to 90% RH (non-condensing) |
| Storage Humidity | 5% to 95% RH (non-condensing) |
| Dimensions (W × D × H) | 145 mm × 86 mm × 25 mm |
More Details
Quality Certifications
Warranty
100% Low Price Guarantee
Network-switch.com provides high-quality products at low wholesale prices
100% Quality Assurance
All items are ORIGINAL and GENUINE only.
Item conditions are "New Sealed". They are fully tested by Ruijie RCNP Engineers.
Free Technical Support
Our FREE Expert Consultancy Support is over the phone, by chat, by email or by login remotely.
100% Money Back Guarantee
You can contact our customer service team to exchange or return any product that you bought from us.
Flexible Secure Payment & Shipment
Verified authorization: Mcafee Secure, VeriSign Secured
Return Material Authorization (RMA) Process
Standard Warranty Policy
Original New Sealed Enterprise Hardware: 3 Years
Original New Sealed Consumer Devices: 1 Year
The Support Contacts
If your Ruijie products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
Original: $494.00
-70%$494.00
$148.20More Images
