Ruijie RG-AP820-I Indoor Wi-Fi 6 AP, 2.976 Gbps, 2.5 G Combo SFP Port
Ruijie RG-AP820-I Indoor Wi-Fi 6 AP, Dual-Band 4-Stream MU-MIMO & 2.976 Gbps Peak, 2.5 Gbps SFP & 1 Gbps PoE Uplink
The Ruijie RG-AP820-I is a high-performance Wi-Fi 6 (802.11ax) dual-radio indoor access point designed to deliver ultra-fast, reliable wireless connectivity in high-density environments such as educational institutions, healthcare facilities, government offices, and enterprise settings. With its advanced features and flexible deployment options, the RG-AP820-I ensures seamless user experiences and efficient network management.
Overview
Highlight
- Dual-Radio Design: Equipped with 2x2 MIMO on both 2.4 GHz and 5 GHz bands, providing a combined peak data rate of up to 2.976 Gbps.
- Advanced Wireless Technologies: Supports OFDMA, MU-MIMO, and 1024-QAM, enhancing efficiency and reducing latency in high-density environments.
- Flexible Deployment: Supports both wall and ceiling mounting options, as well as PoE and DC power supply modes, catering to diverse installation requirements.
- Enhanced Security: Incorporates WPA3 encryption, 802.1X authentication, and PPSK, ensuring robust network security.
- Intelligent Management: Compatible with Ruijie’s Smart Network Commander (SNC) and supports hybrid management modes (Cloud / Controller / Standalone) for simplified operations and maintenance.
Recommended Accessories
| Accessory | Category | Description |
|---|---|---|
| 2.5GBASE-LR SFP Transceiver | Uplink Module | 1310 nm, LC duplex, up to 10 km single-mode fiber backhaul |
| IEEE 802.3at PoE+ Injector | Power | Provides up to 30 W over the 1 GbE RJ45 port |
| USB–ZigBee/RFID Module | IoT Expansion | USB 2.0 adapter for external ZigBee/RFID radios |
| Ceiling/Wall Mount Kit | Installation | Corrosion-resistant bracket for secure indoor mounting |
Comparison with Similar Models
| Model | Antenna & Streams | Peak Rate | Uplinks |
|---|---|---|---|
| RG-AP820-I | 2×[email protected] GHz + 4×4@5 GHz (4 streams) | 2.976 Gbps | 1×2.5 Gbps SFP; 1×1 Gbps RJ45 PoE IN |
| RG-AP820-AR(V3) | Directional, 3×[email protected] + 3×3@5 GHz (6 streams) | 2.976 Gbps | 1×2.5 Gbps SFP; 1×1 Gbps RJ45 PoE IN |
| RG-AP810-I | 4×[email protected] GHz + 4×4@5 GHz (8 streams) | 5.952 Gbps | 2×2.5 Gbps RJ45 PoE+ |
Specification
| Parameter | Specification |
| Model | RG-AP820-I |
| Wi-Fi Standards | IEEE 802.11a/b/g/n/ac/ax |
| Radio Configuration | Dual-radio: 2.4 GHz (2x2 MIMO), 5 GHz (2x2 MIMO) |
| Peak Data Rate | Up to 2.976 Gbps |
| Ethernet Ports | 1 × 10/100/1000BASE-T RJ45 Ethernet port with auto-negotiation, 1 × 2.5GE SFP/RJ45 combo port, 1 × RJ45 console port |
| Antenna Type | Built-in omnidirectional smart antennas (2.4 GHz: 5 dBi, 5 GHz: 5.7 dBi) |
| Power Supply | Supports DC and PoE power supply (IEEE 802.3af/at/bt) |
| Maximum Power Consumption | 12.95 W |
| Security | WPA3, WPA2, WPA, 802.1X, PPSK |
| Management | Supports Fat, Fit, and Cloud modes; compatible with Ruijie SNC |
| Operating Temperature | –10°C to +50°C (14°F to 122°F) |
| Storage Temperature | –40°C to +70°C (–40°F to 158°F) |
| Operating Humidity | 5% to 95% RH (non-condensing) |
| Storage Humidity | 5% to 95% RH (non-condensing) |
| Dimensions (W × D × H) | 220 mm × 220 mm × 49 mm (8.66 in. × 8.66 in. × 1.93 in.) |
| Weight | ≤ 1.2 kg (2.65 lbs) |
| Warranty | Limited lifetime warranty |
