Ruijie RG-AP880-E Indoor Wi-Fi 6 AP, 7.780 Gbps, 8 Streams, 5 GE Combo
Ruijie RG-AP880-E high-performance Wi-Fi 6E Access Point
The RG-AP880-E is a high-density indoor Wi-Fi 6E access point featuring three radios (2.4 GHz, 5 GHz and 6 GHz) and eight spatial streams to deliver up to 7.780 Gbps of aggregate throughput.
It offers a single 5 Gbps SFP/RJ-45 combo uplink, PoE (802.3af/at/bt) and 54 V DC power options, plus hybrid Fit/Fat/Cloud management for flexible large-scale deployments.
Enterprise-grade security (WPA3, PPSK, 802.1X), DFS, LDPC and TxBF ensure robust, seamless coverage in education, healthcare, government and enterprise venues.
Overview
Highlight
- Tri-Radio Design: Equipped with three radios (2.4 GHz, 5 GHz, and 6 GHz), supporting a combined peak data rate of up to 7.780 Gbps, ensuring high-speed wireless access.
- Advanced Wireless Technologies: Supports OFDMA, MU-MIMO, and 1024-QAM, enhancing efficiency and reducing latency in high-density environments.
- Flexible Deployment: Supports both wall and ceiling mounting options, as well as PoE and DC power supply modes, catering to diverse installation requirements.
- Enhanced Security: Incorporates WPA3 encryption, 802.1X authentication, and PPSK, ensuring robust network security.
- Intelligent Management: Compatible with Ruijie’s Smart Network Commander (SNC) and supports hybrid management modes (Cloud / Controller / Standalone) for simplified operations and maintenance.
Recommended Accessories
| Accessory | Category | Description |
|---|---|---|
| XG-SFP-SR-MM850 | 10 Gbps SFP+ Module | 10 GBASE-SR, 850 nm, LC duplex, up to 300 m over OM3/OM4 fiber |
| 2.5GBASE-LR SFP | 2.5 Gbps SFP Module | 1310 nm, LC duplex, up to 10 km over single-mode fiber |
| IEEE 802.3bt PoE++ Injector | Power | Delivers up to 90 W per port for long-reach PoE++ deployments |
| USB-ZIGBEE/RFID Module | IoT Expansion | USB adapter for external ZigBee/RFID radios |
Comparison with Similar Models
| Model | Radios & Streams | Peak Rate | Uplink Ports |
|---|---|---|---|
| RG-AP880-E | 2×[email protected] GHz + 2×2@5 GHz + 4×4@6 GHz (8 streams) | 7.78 Gbps | 1×5 Gbps SFP/RJ-45 combo |
| RG-AP880-AR | 4×[email protected] GHz + 4×4@5 GHz + AI scan (10 streams) | 8.642 Gbps | 1×10 Gbps SFP + 1×5 Gbps RJ-45 |
| RG-AP850-AR(V3) | Quad-radio 2×[email protected]/5 GHz + AI radio (8 streams) | 5.378 Gbps | 1×5 Gbps SFP/RJ-45 combo |
Specification
| Parameter | Specification |
| Model | RG-AP880-E |
| Wi-Fi Standards | IEEE 802.11a/b/g/n/ac/ax |
| Radio Configuration | Tri-radio: 2.4 GHz (2x2 MIMO), 5 GHz (2x2 MIMO), 6 GHz (4x4 MIMO) |
| Peak Data Rate | Up to 7.780 Gbps |
| Ethernet Ports | 1 × 100/1000/2.5G/5GBASE-T RJ45, 1 × 5GE SFP/RJ45 combo port, 1 × 10/100/1000BASE-T RJ45, 1 × RJ45 console port, 1 × USB 3.0 (Type-A connector) |
| Antenna Type | Built-in omnidirectional antennas (2.4 GHz: 5.4 dBi, 5 GHz: 5.2 dBi, 6 GHz: 5.4 dBi) |
| Power Supply | Supports DC and PoE power supply (IEEE 802.3af/at/bt) |
| Maximum Power Consumption | 40 W |
| Security | WPA3, WPA2, WPA, 802.1X, PPSK |
| Management | Supports Fat, Fit, and Cloud modes; compatible with Ruijie SNC |
| Operating Temperature | –10°C to +50°C (14°F to 122°F) |
| Storage Temperature | –40°C to +70°C (–40°F to 158°F) |
| Operating Humidity | 5% to 95% RH (non-condensing) |
| Storage Humidity | 5% to 95% RH (non-condensing) |
| Dimensions (W × D × H) | 230 mm × 230 mm × 51 mm (9.06 in. × 9.06 in. × 2.01 in.) |
| Weight | ≤ 1.0 kg (2.20 lbs) |
| Warranty | Limited lifetime warranty |
More Details
Quality Certifications
Warranty
100% Low Price Guarantee
Network-switch.com provides high-quality products at low wholesale prices
100% Quality Assurance
All items are ORIGINAL and GENUINE only.
Item conditions are "New Sealed". They are fully tested by Ruijie RCNP Engineers.
Free Technical Support
Our FREE Expert Consultancy Support is over the phone, by chat, by email or by login remotely.
100% Money Back Guarantee
You can contact our customer service team to exchange or return any product that you bought from us.
Flexible Secure Payment & Shipment
Verified authorization: Mcafee Secure, VeriSign Secured
Return Material Authorization (RMA) Process
Standard Warranty Policy
Original New Sealed Enterprise Hardware: 3 Years
Original New Sealed Consumer Devices: 1 Year
The Support Contacts
If your Ruijie products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
Original: $914.00
-70%$914.00
$274.20More Images
