Ruijie RG-AP9220 Indoor Wi-Fi 7 AP, 3.570 Gbps, 2.5 GE SFP & 2.5 GBASE-T
Ruijie RG-AP9220 Wi-Fi 7 Dual-Radio AP — 4-Stream 3.57 Gbps & Dual 2.5 GbE SFP/RJ45 Uplinks
TThe RG-AP9220 is Ruijie’s dual-radio indoor access point compliant with IEEE 802.11be (Wi-Fi 7), offering four spatial streams for a combined peak data rate of 3.570 Gbps.
It supports both DC and PoE power options and features one 2.5 GBASE-T RJ45 port and one 2.5 GbE SFP uplink for seamless integration into copper or optical networks, making it ideal for classrooms, offices, and retail environments
Overview
Highlight
- Wi-Fi 7 Compliance: Supports the latest IEEE 802.11be standard, offering enhanced throughput and reduced latency.
- Dual-Radio Design: Equipped with 2x2 MIMO on both 2.4 GHz and 5 GHz bands, providing a combined peak data rate of up to 3.570 Gbps.
- Flexible Networking: Features both 2.5GE SFP and 2.5GBASE-T ports, allowing for versatile deployment options and future-proof scalability.
- Smart Antennas: Built-in intelligent antennas dynamically adjust signal strength and coverage to optimize device performance.
- Digital Twin Network: Supports intelligent operations and maintenance functions, improving network efficiency by up to 30%.
- Enhanced Security: Incorporates advanced security features, including WPA3 encryption, to safeguard network integrity.
- Energy-Efficient Design: Supports Energy Efficient Ethernet (EEE) and auto power-down modes to reduce power consumption.
- Efficient Management: Compatible with Ruijie’s Smart Network Commander (SNC) for simplified operations and maintenance.
Recommended Accessories
| Accessory | Category | Description |
|---|---|---|
| 2.5GBASE-LR SFP Module | Uplink Module | 2.5 GbE SFP single-mode, 1310 nm, LC duplex, up to 10 km |
| 2.5GBASE-SR SFP Module | Uplink Module | 2.5 GbE SFP multimode, 850 nm, LC duplex, up to 300 m |
| IEEE 802.3at PoE+ Injector | Power | Provides up to 30 W for the 2.5 GBASE-T port in PoE+ mode |
Comparison with Similar Models
| Model | Radios & Streams | Peak Rate | Uplinks |
|---|---|---|---|
| RG-AP9220 | 2×[email protected] GHz + 2×2@5 GHz (4 streams) | 3.570 Gbps | 1×2.5 GbE SFP; 1×2.5 GBASE-T RJ45 |
| RG-AP9861-R | 4×[email protected] GHz + 4×4@5 GHz + 4×4@6 GHz + AI (18 streams) | 24.436 Gbps | 2×10 GbE SFP+/RJ45 |
| RG-AP820-I | 2×[email protected] GHz + 2×2@5 GHz (4 streams) | 2.976 Gbps | 1×2.5 GbE SFP; 1×1 GbE RJ45 PoE |
Specification
| Parameter | Specification |
| Model | RG-AP9220 |
| Wi-Fi Standards | IEEE 802.11be/ax/ac/n |
| Radio Configuration | Dual-radio, 2x2 MIMO on both 2.4 GHz and 5 GHz bands |
| Peak Data Rate | Up to 3.570 Gbps |
| Ethernet Ports | 1 × 2.5GE SFP port, 1 × 2.5GBASE-T port |
| Antenna Type | Built-in smart antennas |
| Power Supply | Supports DC and PoE power supply |
| Security | WPA3, WPA2, WPA, 802.1X, PPSK, etc. |
| Management | Supports Fat, Fit, and Cloud modes; compatible with Ruijie SNC |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Operating Humidity | 10% to 90% RH (non-condensing) |
| Storage Humidity | 5% to 95% RH (non-condensing) |
| Dimensions (W × D × H) | 220 mm × 220 mm × 48 mm (8.66 in. × 8.66 in. × 1.89 in.) |
| Weight | ≤ 1.2 kg (2.65 lbs) |
| Warranty | Limited lifetime warranty |
