Ruijie RG-AP850-AR(V3) Indoor Wi-Fi 6 AP, 5.378 Gbps, 8 Spatial Streams
Ruijie RG-AP850-AR(V3) Indoor Wi-Fi 6 AP, Quad-Radio AI-Scan & 5.378 Gbps, 8-Stream MU-MIMO
The RG-AP850-AR(V3) is Ruijie’s high-density Wi-Fi 6 indoor access point, featuring a quad-radio architecture (2.4 GHz + two 5 GHz client radios + one AI-scan radio) that delivers eight spatial streams and an aggregate peak data rate of 5.378 Gbps.
It supports up to 1 552 concurrent clients, with seamless roaming driven by the AI scan radio (< 30 ms handoff, < 0.5 % packet loss) and real-time, full-band network scanning that never impacts user traffic.
Uplink flexibility comes from a 5 Gbps SFP/RJ45 combo port plus a 1 Gbps RJ45 port, and it can be powered via IEEE 802.3af/at PoE or 54 V DC. Unified WIS Cloud management enables zero-touch provisioning, 24 × 7 optimization, and real-time fault warning for simplified O&M.
Overview
Highlight
- Quad-Radio Design: Equipped with four radios (2.4 GHz, two 5 GHz, and AI radio), supporting a combined peak data rate of up to 6.245 Gbps, ensuring high-speed wireless access.
- Advanced Wireless Technologies: Supports OFDMA, MU-MIMO, and 1024-QAM, enhancing efficiency and reducing latency in high-density environments.
- Flexible Deployment: Supports both wall and ceiling mounting options, as well as PoE and DC power supply modes, catering to diverse installation requirements.
- Enhanced Security: Incorporates WPA3 encryption, 802.1X authentication, and PPSK, ensuring robust network security.
- Intelligent Management: Compatible with Ruijie’s Smart Network Commander (SNC) and supports hybrid management modes (Cloud / Controller / Standalone) for simplified operations and maintenance.
Recommended Accessories
| Accessory | Category | Description |
|---|---|---|
| XG-SFP-SR-MM850 | 10 Gbps SFP+ | 10GBASE-SR multimode, 850 nm LC duplex, up to 300 m over OM3/OM4 fiber |
| IEEE 802.3at PoE+ Injector | Power | Supplies up to 30 W to the RJ45 uplink port |
| USB–ZigBee/RFID Module | IoT Expansion | USB 3.0 adapter for external ZigBee or RFID radios |
| Ceiling/Wall Mount Kit | Installation | Corrosion-resistant bracket for flexible indoor mounting |
Comparison with Similar Models
| Model | Radios & Streams | Peak Rate | Uplinks | Max Clients |
|---|---|---|---|---|
| RG-AP850-AR(V3) | Quad-radio: 2×[email protected] GHz + 2×2@5 GHz×2 + AI 2×2 | 5.378 Gbps | 1×5 Gbps SFP/RJ45 combo; 1×1 Gbps RJ45 | 1552 |
| RG-AP820-I | Dual-radio: 4×[email protected] GHz + 4×4@5 GHz | 5.378 Gbps | 1×5 Gbps combo; 1×1 Gbps RJ45 | 1024 |
| RG-AP820-AR | Tri-radio: 2×[email protected] GHz + 2×2@5 GHz + AI scan 2×2 | 2.976 Gbps | 1×5 Gbps SFP; 1×1 Gbps RJ45 | 1024 |
Specification
| Parameter | Specification |
| Model | RG-AP850-AR(V3) |
| Wi-Fi Standards | IEEE 802.11a/b/g/n/ac/ax |
| Radio Configuration | Quad-radio: 2.4 GHz (2x2 MIMO), 5 GHz (2x2 MIMO x2), AI Radio (2x2 MIMO) |
| Peak Data Rate | Up to 6.245 Gbps |
| Ethernet Ports | 1 × 100/1000/2.5G/5GBASE-T RJ45, 1 × 5GE SFP/RJ45 combo port, 1 × 10/100/1000BASE-T RJ45, 1 × RJ45 console port, 1 × USB 3.0 (Type-A connector) |
| Antenna Type | Built-in omnidirectional antennas (2.4 GHz: 5.4 dBi, 5 GHz: 5.2 dBi) |
| Power Supply | Supports DC and PoE power supply (IEEE 802.3af/at/bt) |
| Maximum Power Consumption | 40 W |
| Security | WPA3, WPA2, WPA, 802.1X, PPSK |
| Management | Supports Fat, Fit, and Cloud modes; compatible with Ruijie SNC |
| Operating Temperature | –10°C to +50°C (14°F to 122°F) |
| Storage Temperature | –40°C to +70°C (–40°F to 158°F) |
| Operating Humidity | 5% to 95% RH (non-condensing) |
| Storage Humidity | 5% to 95% RH (non-condensing) |
| Dimensions (W × D × H) | 230 mm × 230 mm × 51 mm (9.06 in. × 9.06 in. × 2.01 in.) |
| Weight | ≤ 1.0 kg (2.20 lbs) |
| Warranty | Limited lifetime warranty |
